Remote Operation 13-3 General Purpose Commands
PowerXpert UG PN: 10585-00020 Rev. C 13-15
FORWARD?
Description: Gets the forward measurement mode.
Syntax: FORWARD? +LF
Return Value: num = 1 to 6
Remarks: 1 – Forward Average
2 – Crest Factor
3 – Burst Average Manual
4 – Peak Envelope Power
5 – Burst Average Auto
6 – CCDF
Compatible Sensor: MA24105A
REVERSE
Description: Sets the reverse measurement mode
Syntax: REVERSE <num> +LF
Details: num = 1 to 4
Remarks: 1 – Reverse Average
2 – Reflection Coefficient
3 – Return Loss
4 – Standing Wave Ratio (VSWR)
Compatible Sensor: MA24105A
REVERSE?
Description: Gets the reverse measurement mode
Syntax: REVERSE? +LF
Return Value: num = 1 to 4
Remarks: 1 – Reverse Average
2 – Reflection Coefficient
3 – Return Loss
4 – Standing Wave Ratio (VSWR)
Compatible Sensor: MA24105A
VIDEOBW
Description: Sets the video BW
Syntax: VIDEOBW <num> +LF
Details: num = 0 to 2
Return Value: OK or ERR
Remarks: 0 – Full
1 – 4 kHz
2 – 200 kHz
Compatible Sensor: MA24105A
